Case Study 3

CAD CAM Solution



One of the largest manufacturers of Aircraft parts located in USA.

Business Challenge

  • Remotely providing programming support for Manufacturing.
  • High quality and accurate deliverables.


Ignis used Vericut Software for simulating each part before sending it to the customer.


Ignis applied Master Tool list approach for programming parts on Machine Cells. Documented all the discrepancies and errors identified as Lessons Learnt. Ignis used 3D models of all machine accessories, fixtures, tombstones, tool holders available at Customer during simulation activities.


Client Benefits

The video of simulation of manufacturing as per the codes helps customer understand programming efficiency similar to the actual G& M codes which get into the machine. The customer need not pay for any re programming efforts, thereby minimizing cost and time to modify the part to comply with blue print tolerances.
